Formula:                                                                    CF3CH2F

B.P., °C:                                                                          -43

Critical temperature, °C:                                                    45

Vapor pressure, MPa@25°C:                                          0.600

Vapor density,(Air=1.0)@25°C:                                       2.4

Liquid density,25°C g/cm3:                                             71.4

ODP(CFC-11=1):                                                             0

GWP(CO2=1):                                                              2624

Non-refillable cylinder:11.3kg

Refillable cylinder:100L, 800L, 926L, 1000L;

Portable tank: ISO TANK, TON TANK

Refillable cylinder:100L, 800L, 926L, 1000L;

Portable tank: ISO TANK, TON TANK

Appearance:         Clear,Colorless liquid and vapor

Odor:                    Faint ethereal odor

Purity,≥%:                99.9

Moisture, ≤ %:              0.001

Acidity, ≤ %:               0.0001

Residue on evaporation, ≤ %: 0.01

R-422D is a refrigerant gas which can be used easily.Its ODP (ozone-depleting potential) is 0,R-422D will show a drop in capacity compared to -22, which usually translates into slightly increased run times in a properly sized system. Some system components may need to be changed if excess pressure drop develops. The hydrocarbon component in R-422D helps promote oil return in systems containing mineral oil or alkylbenzene. Although HFC refrigerants won’t mix with these oils, the hydrocarbon addition thins the oil and keeps it moving around the loop. More complicated piping arrangements or large hold-up volumes may still require some oil be changed to POE.
